Description
180° SHEETED CATTLE CROWDING TUB
FREE SHIPPING
Bring cattle from your holding pen into the working alley with Red River Arenas' 180° Sheeted Cattle Crowding Tub. The half-circle layout measures approximately 20' across by 10' deep and uses a locking sweep gate to guide cattle toward the alley opening.
This tub is sold separately for customers who already have an alley or want to build their own cattle-working setup. Tub-and-alley packages are also available with our 10' Sheeted Straight Alley or 10' Adjustable Sheet Metal Cattle Alley.
Locking Sweep Gate
The sweep gate moves cattle toward the alley entrance, while its spring-loaded locking mechanism holds the gate at positions around the tub to prevent cattle from pushing it backward.
Sheeted Lower Sides
14-gauge galvanized sheet metal covers the lower portion of the tub panels and sweep gate, creating a visual barrier that helps reduce outside distractions. Open upper rails provide visibility into the tub.
Connect to Your Alley
The straight side includes a gate, an approximately 8' panel section, and an approximately 2' opening for an alley connection. Connect a compatible existing alley, a Red River Arenas 10' Sheeted Straight Alley, or a 10' Adjustable Sheet Metal Cattle Alley. When connecting another manufacturer's equipment, verify the opening dimensions and connection requirements before ordering.
Left- or Right-Hand Configuration
Please specify your preferred left- or right-hand configuration when ordering. If no direction is specified, the tub will ship in the configuration shown in the product photos.
Complete Tub Includes:
- 1 sheeted sweep gate
- 1 tub combo gate section
- 1 - 10' double-spool sheeted curved panel
- 2 - 10' single-spool sheeted curved panels
- 1 bottom brace with hole
- 1 bottom brace with peg
- 1 tub handle assembly with grip, bolt, locknut, and spring
- 12 fishhook pins
Specifications:
- Layout - 180° half-circle
- Approximate Footprint - 20' across x 10' deep
- Radius - Approximately 10'
- Lower Sheeting - 14-gauge galvanized sheet metal
- Galvanized steel construction
- Locking sweep gate
- Left- or right-hand configuration available; specify when ordering
- Ships unassembled; assembly required
Tub only. Alley and squeeze chute are not included.
