180° OPEN CATTLE CROWDING TUB
FREE SHIPPING
Guide cattle from your holding pen into the working alley with Red River Arenas' 180° Open Cattle Crowding Tub. The half-circle layout measures approximately 20' across by 10' deep and uses a locking sweep gate to move cattle toward the alley entrance.
This stand-alone tub is designed for customers who already have an alley or want to build their own cattle-working setup. The open-sided construction provides visibility throughout the tub without sheet-metal panels.
Locking Sweep Gate
The sweep gate guides cattle toward the alley opening. Its spring-loaded locking mechanism holds the gate at positions around the tub to prevent cattle from pushing it backward.
Open Galvanized Construction
Open rails allow handlers to see cattle throughout the tub. The galvanized steel construction includes curved perimeter panels, an open sweep gate, and a combo section for the alley connection.
Connect to Your Alley
The straight side includes a gate, an approximately 8' panel section, and an approximately 2' opening for an alley connection. Connect a compatible existing alley or choose a Red River Arenas open, sheeted straight, or adjustable alley. When connecting another manufacturer's equipment, verify the opening dimensions and connection requirements before ordering.
Left- or Right-Hand Configuration
Please specify your preferred left- or right-hand configuration when ordering. If no direction is specified, the tub will ship in the configuration shown in the product photos.
Complete Tub Includes:
- 1 open sweep gate
- 1 tub combo section
- 1 - 10' double-spool open curved panel
- 2 - 10' single-spool open curved panels
- 1 bottom brace with hole
- 1 bottom brace with peg
- 1 tub handle assembly with grip, bolt, locknut, and spring
- 12 fishhook pins
Specifications:
- Layout - 180° half-circle
- Approximate Footprint - 20' across x 10' deep
- Radius - Approximately 10'
- Open-sided, non-sheeted construction
- Galvanized steel construction
- Locking sweep gate
- Left- or right-hand configuration available; specify when ordering
- Ships unassembled; assembly required
Tub only. Alley and squeeze chute are not included.
