ADD ON- 10' Adjustable Sheet Metal Cattle Alley
Description
ADD ON - 10' ADJUSTABLE SHEET METAL CATTLE ALLEY
FREE SHIPPING
IMPORTANT: This is an ADD ON section only and cannot be ordered as a stand alone.
Extend an original Red River Arenas Adjustable Sheet Metal Cattle Alley with an additional 10' working section. Order one add-on to create a 20' alley or two add-ons to create a 30' alley.
This add-on handles calves through mature cattle and adjusts from 10-1/2" to 32-1/4" wide, allowing you to size each section for the cattle being worked.
Independent Width Adjustment
Both side panels can be adjusted independently at the top and bottom. Adjust one side or both sides to change the alley width, maintain the built-in V-bottom, or increase the taper when needed. Spring-loaded latches secure each panel within the adjustable end arches.
Solid Lower Sides with Open Access
The lower portion of each alley panel is covered with 14-gauge galvanized sheet metal to create a solid visual barrier and reduce outside distractions. The upper portion remains open, providing access to cattle while they move through the alley.
Chain-Suspended Butt Bar
The included hang-down butt bar suspends from a chain. As cattle move forward, the butt bar passes over the animal and drops behind it to form a back block that discourages backing.
Extend Your Adjustable Alley
This add-on connects to an original adjustable alley section using the included fishhook pins. Multiple 10' add-ons may be connected when a longer working alley is needed. The sections do not have to be anchored or bolted down.
Add-On Section Includes:
- 2 adjustable alley panels
- 2 adjustable alley arches
- 1 adjustable alley bar
- 1 chain-suspended butt bar/hang-down gate
- 4 fishhook pins
Specifications:
- Length: 10'
- Side Panel Height: 6'
- Overall Height: 6' 7"
- Adjustable Inside Width: 10-1/2" to 32-1/4"
- Panel Frame: 1-1/2" square galvanized tubing, 16 gauge
- Lower Sheeting: 14-gauge galvanized sheet metal
- Livestock Range: Calves through mature cattle
- Ships unassembled
- No anchoring or bolting required
